LEGRAND MOSAIC Series User Manual

22
PRESENTATION AND INSTALLATION OF DEVICES
OFF
0 782 45/47
0 782 02
0 782 02
C10
0 783 77/78/79: REMOTE CONTROL MODULES
Technical characteristics
n Power supply: 100 - 240 V
n Operating temperature: 0 to 35°C
n Storage temperature: -20 to 70°C
n Dimensions: 230 x 71 x 44 mm
n Installation: in suspended ceiling or technical cabinet
Remote control module for luminaires or bedhead strips for controlling 4 lighting outputs Cat. No. 0 783 77
Compatible with hand-held remote control unit Cat. No. 0 782 02.
These units are used to control SELV functions (lighting, roller
blinds, and one additional function) via hand-held remote control
units.
For mounting in suspended ceilings or in technical cabinets
between the rooms.
This product must be used on a single phase.
+
35°C
0°C
+
+
+ 35°C
0°C
+
+
+ 35°C
0°C
+
+
+ 35°C
0°C
+
+
+ 35°C
0°C
+
+
+ 35°C
0°C
+
+
+ 35°C
0°C
+
+
+ 35°C
0°C
+
+
230 VA
500 W
2 A
1000 W
4.3 A
500 VA
2 A
500 VA
2 A
500 VA
2 A
500 VA
2 A
1 x 500 VA
2 A
110 VA
250 W 500 W 250 VA 250 VA 250 VA 250 VA 1 x 250 VA

LEGRAND MOSAIC Series Specifications

General

Series	MOSAIC
Category	Switch
Brand	LEGRAND
Modular	Yes
Color	White
Material	Plastic
Protection Rating	IP20
Voltage Rating	250 V
Current Rating	10 A
Standards	IEC 60669-1
Installation	Flush mounting
Color Options	White, Black
