LEGRAND MOSAIC Series - Page 9

9
PRESENTATION AND INSTALLATION OF DEVICES
MOSAIC NURSE CALL UNIT
Telephony package
Volt-free contact
interface unit
16 I/O to IP
Volt-free contact
interface unit
16 I/O to IP
Volt-free contact
interface unit
16 I/O to IP
Volt-free contact
interface unit
16 I/O to IP
Volt-free contact
interface unit
16 I/O to IP
Volt-free contact
interface unit
16 I/O to IP
Volt-free contact
interface unit
16 I/O to IP
Volt-free contact
interface unit
16 I/O to IP
Volt-free contact
interface unit
16 I/O to IP
Volt-free contact
interface unit
16 I/O to IP
230 V
or PoE
230 V
or PoE
230 V
or PoE
230 V
or PoE
Management module Cat. No. 0 782 12
9-room Neurology ward
Riser
VDI package
ELV equipment room
Main cross-connect
cabinet
3
rd
oor
2
nd
oor
1
st
oor
Management module Cat. No. 0 782 12
Nurse call package
9-room Ophthalmology ward
Management module Cat. No. 0 782 12
Nurse call package
18-room Dermatology ward
Management module Cat. No. 0 782 12
Nurse call package
36-room Urology ward
Management module Cat. No. 0 782 12
Nurse call package
30-room General surgery department
Nurse call package
12-room Cardiology ward
Management module Cat. No. 0 782 12
Nurse call package
Telephony package
UTP/FTP cable Cat. 5e minimum
RS232
DECT
TERMINAL
DECT
TERMINAL
DECT
TERMINAL
Cables with 2 x 0.6 mm
2
pairs (50 m max) or 0.9 mm
2
pairs (100 m max)
*Répartiteur Général Informatique (main cross-connect)
23
o
r
2
o
r
2
o
r
V
o
E
90 m max.
90 m max.
Autocom cabinet
PABX/IPBX
Traceability on standard computer with icon
congured as a xed IP address.
For use by:
- Nurses
- Maintenance
- Management
Congured by the network integrator.
Telephone
coupler with
xed IP address
INSTALLATION PRINCIPLE WITH CALLFORWARDING OVER DECT AND TRACEABILITY ON TELEPHONE COUPLING PRODUCT AND CORRIDOR DISPLAY UNITS TELEPHONY PACKAGE NOT SUPPLIED BY LEGRAND
