2.5 CS Components
008471_001
a
b
c
e
f
d
g
h
a DISTO with camera
b
Scr
een
c Keyboard
d Connector cover
e Power socket
f SD card slot
g USB A host port
h LEMO port (USB and serial)
008472_001
a
b
c
h
e
f
d
g
i
a Hand strap
b
T
hread for screwing on hand
strap or utility hook
c Expansion cover
d Digital camera with flash
e Stylus
f Battery compartment
g SIM card slot under the bat-
tery
h Socket for fastening clip of
the hand strap
i Tether for the stylus
2.6 GS07 Components
0016301_001
a
b
c
d
e
a ON/OFF button
b
LEDs
c
LEMO port including USB port
d Antenna Reference Plane
(ARP)
e Battery compartment
Upside of CS20
Underside of CS20
GS07 components
