6.3.2 CS20
•
F
C
C Part 15, 22 and 24 (applicable in US)
•
Hereby, Leica Geosystems AG declares that the radio equipment type
CS20 is in compliance with Directive 2014/53/EU and other applicable
European Directives.
The full text of the EU declaration of conformity is available at the fol-
lowing Internet address: http://www.leica-geosystems.com/ce.
Class 1 equipment according to European Directive 2014/53/EU
(RED) can be plac
ed on the market and be put into service with-
out restrictions in any EEA member state.
•
The c
onformity for countries with other national regulations not covered
by the FCC part 15, 22 and 24 or European Directive 2014/53/EU has to
be approved prior to use and operation.
Type Frequency band [MHz]
CS20, Bluetooth 2402 - 2480
CS20, RCS 2402 - 2480
CS20, GSM (2G)/UMTS (3G) UMTS 800 / 850 / 900 / 1900 / 2100
GSM 850 / 900 / 1800 / 1900
HSPA Download: 7.2 Mbit/s
HSP
A Upload: 5.76 Mbit/s
CS20, WLAN 2400 - 2484
CS20,3.75G GSM/UMTS/
CDMA
Quad-Band GSM & Penta-Band UMTS & Tri-
Band CDMA 800 / 1900
CTR20 2402 - 2480MHz
Type Output power [mW]
CS20, Bluetooth 10
CS20 < 20
CS20, GSM (2G)/UMTS (3G) EGSM850/900 2000
CS20, GSM (2G)/UMTS (3G) GSM1800/1900 1000
CS20, GSM (2G)/UMTS (3G) UMTS2100 250
CS20, GSM (2G)/UMTS (3G) EDGE850/900 500
CS20, GSM (2G)/UMTS (3G) EDGE1800/1900 400
CS20, WLAN (802.11b) - 11 Mbit/s 100
CS20, WLAN (802.11g) - 54 Mbit/s 80
CS20, WLAN (802.11n) - 65 Mbit/s 80
CS20, CDMA BC0 & BC10 (800)/BC1 (1900) 250
Type Antenna Gain
[dBi]
Connector Frequency
band
[M
Hz]
CS20,
Bluetooth
Integrated
antenna
2 - 2400-2480
Conformity to
nat
ional regulations
Frequency band
Output power
Antenna
54 Technical Data
