Software for Description
CGR UHF radio firmware update instruc-
tions
•
Download the mos
t recent CS20 firm-
ware file from
https://myworld.leica-geosystems.com.
•
Copy the CS20 firmware file into the
\SYSTEM directory of the Leica SD card.
•
Connect the CGR radio to the CS field
controller and configure the CGR radio as
RTK device. Refer to the Leica Captivate
Technical Reference Manual.
•
Select the firmware file to upload and
start the update process. A message will
appear when the upload is complete.
2.3.2 Power Concept
Use the batteries, chargers and accessories recommended by Leica Geosystems
to ensur
e the correct functionality of the instrument.
Model Power supply
All CS models Internally by GEB331 battery, OR
Externally by GEV276 cable, OR
Externally by GEV219 cable
If an external power supply is connected and the internal
bat
tery is inserted, then the external power is used. The
internal battery is charged.
Please note: Charging functionality is not available for CS20
field controller.
CTR20, CGR4 Externally by the field controller.
Please note: Expansion pack support is not available for CS20
field controller.
GS07 Internally by GEB212 battery, OR
Externally by GEV219 cable
If an external power supply is connected and the internal
battery is inserted, then the external power is used.
2.3.3 Data Storage Concept
Data is stored on a memory device. The memory device can be an SD card, USB
stick o
r internal memory.
Device Description
SD card All field controllers have an SD card slot fitted as standard.
An SD card can b
e inserted and removed. Available capacity:
1 GB, 8 GB.
USB stick All field controllers have a USB port fitted as standard.
Internal
memory
All field controllers have an internal memory fitted as stand-
ard. Available capacity: 2 GB.
General
Power options
Description
Memory device
Description of the System 21
