5. After successful loading, the licence key file is renamed with the suf-
f
ix "..._loaded".
☞
If the software maintenance licence has expired:
Contact your local service partner to update the software on the
product.
☞
If the licence activation fails:
Contact your local service partner or create a new support request on
myWorld.
For instruments with a Keyboard Display Unit
R
efer to the Captivate Technical Reference Manual for information about the
license upload.
2.2.2 Power Concept
Use the batteries, chargers and accessories recommended by Leica Geosystems
t
o ensure the correct functionality of the instrument.
Model Power supply
all TS models Internally by GEB222 battery, OR
Externally by GEV52 cable and GEB371 battery.
If an external power supply is connected and the internal
ba
ttery is inserted, then the external power is used.
SmartAn-
tenna
Internally via GEB212 battery fitted into the antenna.
2.2.3 Data Storage Concept
For instruments with a four button keyboard without display:
Da
ta storage is only possible on the connected controller. On a CS20, the avail-
able memory devices are an SD card and an internal memory.
For instruments with a keyboard display unit:
Da
ta is stored on a TS memory device. The memory device can be an SD card
or internal memory. For data transfer an USB stick can also be used.
Device Description
SD card All instruments have an SD card slot fitted as standard. An SD
car
d can be inserted and removed. Available capacity: 1 GB
and 8 GB.
USB stick All instruments have a USB port fitted as standard.
Internal
memory
All instruments have an internal memory fitted as standard.
Available capacity: 2 GB.
☞
While other SD cards/USB sticks can be used, Leica Geosystems rec-
o
mmends to only use Leica SD cards/USB sticks and is not responsible
for data loss or any other error that can occur while using a non-Leica
SD card/USB stick.
General
Power options
Description
Memory device
28 Description of the System
