Leica TS13 - Long Range and ATR Technical Data

Beam interruptions, severe heat shimmer and moving objects within the beam
pa
th can result in deviations of the specified accuracy. The display resolution is
0.1 mm.
Type Description
Principle Phase measurement
Type Coaxial, visible red laser
Carrier wave 658nm
Measuring system System Analyzer Basis 100MHz - 150MHz
7.5 Automatic Target Aiming (ATR)
Reflector Range (Target Aiming)
[m] [ft]
Standard prism
(G
PR1)
1000 3300
360° prism
GRZ4, GRZ122)
800 2600
360° Mini prism
(GRZ101)
350 1150
Mini prism
(GMP101)
500 1600
Reflector tape
60 mm x 60 mm
45 150
☞
The maximum range can be restricted by poorer conditions, for
example rain.
Shortest measuring distance: 360° prism (Target aiming): 1.5 m
Shortest measuring distance: 360° prism (Target locking): 5 m
Type Accuracy
ATR angle accuracy Hz, V (std. dev. ISO 17123-3) 1 " (0.3 mgon)
Base Positioning accuracy (std.dev.) ± 1 mm
Type Value
Typical search time in field of view 1.5 s
Field of view 1°25’/1.55 gon
Definable search windows Yes
Type Description
Principle Digital image processing
Type Infrared laser
Characteristics
Range of tar-
ge
t aiming/
target locking
ATR accuracy with the
G
PR1 prism
Searching
Characteristics
