Accuracy refers to measurements to standard prisms.
Distance
m
easuring
mode
Standard
deviation
ISO 17123-4,
standard prism
Standard
deviation
ISO 17123-4,
tape
Measurement
time, typical [s]
Once 1 mm + 1.5 ppm 3 mm + 2 ppm 2.4
Once & fast 2 mm + 1.5 ppm 3 mm + 2 ppm 2.0
Continuously 3 mm + 1.5 ppm 3 mm + 2 ppm < 0.15
Repeatedly &
average
1 mm + 1.5 ppm 1 mm + 1.5 ppm -
Beam interruptions, severe heat shimmer and moving objects within the beam
pa
th can result in deviations of the specified accuracy.
The display resolution is 0.1 mm.
Type Description
Principle Phase measurement
Type Coaxial, visible red laser
Carrier wave 658 nm
Measuring system System Analyzer Basis 100 MHz - 150 MHz
7.3 Distance Measurement without Reflectors
(N
on-Prism mode)
R500
Kodak Gray Card Range D Range E Range F
[m] [ft] [m] [ft] [m] [ft]
White side, 90 %
r
eflective
250 820 400 1310 >500 >1640
Grey side, 18 %
reflective
150 490 200 660 >200 >660
R1000
Kodak Gray Card Range D Range E Range F
[m] [ft] [m] [ft] [m] [ft]
White side, 90 %
r
eflective
800 2630 1000 3280 >1000 >3280
Grey side, 18 %
reflective
400 1320 500 1640 >500 >1640
Range of Measurement: 1.5 m - 1200 m
Display unambiguous: up to 1200 m
Range Description
D Object in strong sunlight, severe heat shimmer
E Object in shade, or overcast
Accuracy
Characteristics
Range
Atmospheric condi-
t
ions
Technical Data 61
