5.4006.8501.0 B
6-2 Maintenance
6.3 Maintenance Procedures
6.3.1 Clean the Charging Strips and the Charging Electrodes
Make sure that after cleaning the charging electrodes slide over the middle of the
charging strips when the machine parks.
Preparation
1. Disconnect the main power supply to the charging station.
2. Manually drive the machine to a clean and quiet location (see Manually drive the Machine on page 5-
6).
3. Switch Off the Machine (see page 5-3).
Clean
Unexpected cow movement.
Risk of being crushed or trampled.
Block the cow traffic.
1. Thoroughly clean the charging strips (1), (2) (see figure 41 on page 6-3) of the machine with sand
paper or a steel brush.
2. Thoroughly clean both electrodes of the charging station (3) with sand paper.
in n o vato rs in ag ricu ltu r e
