5.4006.8501.0 B
Specifications 3-1
3 Specifications
Specifications Vehicle
Dimensions and Weight.
• Length: 1362 mm (53.60 in).
• Width: 860 mm (33.86 in).
• Height: 575 mm (22.64 in).
• Weight: 340 kg (750 lb).
• Sensing ring height: 102 mm (4.02 in).
Battery.
• Number of batteries: 1.
• Nominal voltage: 12 V.
• Capacity: 55 Ah.
• Charging time: 6 hours maximum.
• Spare capacity: 120 min.
• Weight 19.5 kg (42.9 lb).
Driving speed.
10.8 to 18 m/min (display: 180 - 300 mm/sec)
Routes.
• Max. number of different programmable routes: 16.
• Max. number of actions per route: 125.
• Max. number of time-route combinations per time path: 48
• Max. duration of a time path: 24 hours
Drive on thresholds and level
differences.
< 10 mm (0.4 in).
Cleaning capacity. Max. cleaning capacity: 918 m²/h at 18 m/min.
Navigation sensors.
• Detection of the driving direction: Gyroscope.
• Distance measurement to wall: Ultrasonic sensor.
• Travelled distance: Measured via encoders on the motors.
Drive mechanism. 2 electric motors, each motor driving one wheel.
Water system.
• Total water tank capacity: 30 l (7.9 gal).
• Total water output via nozzles: Max. 1 l/min (0.26 gal/min).
Average power consumption.
0.05 kWh.
Noise emission in accordance
with EN-ISO 4871
Emission sound pressure level
(LpA).
< 70 dB.
Floor. Suited for all level slatted floors.
Drive on slopes. < 6° (10.5 cm per 100 cm).
