LELY Discovery 90 SW User Manual

5.4006.8501.0 B
3-2 Specifications
Specifications Charging station
Dimensions and weight.
• Width: 380 mm (15.0 in).
• Depth: 220 mm (8.7 in).
• Height: 1650 - 2050 mm (65.0 - 80.7 in).
• Weight(excluding floor column): 40 kg (88 lb).
Floor column (optional)
dimensions and weight.
• Width: 370 mm (14.6 in).
• Depth: 100 mm (3.9 in).
• Height: 2100 mm (82.7 in).
• Weight: 44 kg (97 lbs).
Electrical properties battery
charger (grey).
• Type: Impulse ‘L’ .
• Input voltage: 230 VAC (50 Hz) or 110 VAC (60 Hz).
• Nominal output voltage: 12 VDC.
• Max. charge current: 20 A.
• Max. power: 295 W.
Electrical properties battery
charger (blue).
• Type: Impulse ‘II L’ .
• Input voltage: 220 - 240 VAC (50–60 Hz).
• Nominal output voltage: 12 VDC.
• Max. charge current: 20 A.
• Max. power: 400 W.
Specifications Water Filling Station
Dimensions and weight Water
filling station:
• Width: 406 mm (16.0 in)..
• Height: 282 mm (11.1 in).
• Depth: 231 mm (9.1 in).
• Weight: 11 kg (24.3 lb).
Dimensions and weight
Header tank (optional):
• Width: 330 mm (13.0 in).
• Height: 210 mm (8.3 in).
• Depth: 200 mm (7.9 in).
• Weight: 6 kg (13.2 lb); completely filled: 14 kg (31 lb).
• Hose pilar thread: 1/2 in BSP.
• Tube connection diameter: 13 mm (0.5 in).
