5.1501.8502.0 A
5-4 Operating Instructions
The number of sample bottles that can be installed in the Shuttle is model and country-
dependant.
2. Select at Rack type (max. nr. of bottles) the applicable number of sample bottles.
1. Button Save.
3. Set at Rack number the rack number of the installed rack.
1. Set the value with the keypad or use the button
to lower or to raise the value.
2. Button Save.
4. Set at Current bottle number in rack the current sample bottle number in the rack.
1. Set the value with the keypad or use the button
to lower or to raise the value.
The default value is 1. For continuing milk sampling after an alarm, set the current sample bottle.
2. Button Save.
5. Set at Last bottle number in rack the last sample bottle number in the rack.
1. Set the value with the keypad or use the button
to lower or to raise the value.
2. Button Save.
6. Set at No. of empty bottles for alarm the number of empty sample bottles before an alarm is
generated.
1. Set the value with the keypad or use the button
to lower or to raise the value.
• The default value is 3.
• 0 (no phone call) < x (CRS+ phone call).
• If x > 0 then a call out is generated.
2. Button Save.
The Fill time sample bottle (Shuttle) should be adjusted so that the spoon does not
overflow. The Fill time sample bottle (Shuttle) for a spoon with 10 ml (0.34 oz) is
shorter than for a 50 ml (0.34 oz) spoon.
