Attaching the implement
51
− Turn the plough into the left-handed po-
sition.
−
Fit the bolt (5) in the angular adjustment
mechanism for the right-handed side. To
insert the bolt (5) into the h
older, bend
the sprung side piece downwards as
shown. The sprung side piece locks the
bolt when it is in place.
The bolt (5) for the right-
handed side is stored in
the toolbox when not in
use. This bolt must be fit-
is used.
o Ensu
re that the bolts (5) for the
angular adjustment mechanism
are fitted on both sides before
starting work.
− Raise the plough frame.
Before transportation on public roads
−
Install the prescribed lighting equipment,
see «Lighting equipment , page 60».
− Turn the plough frame into the half-
turned position.
