GEL 2444 M , GEL 2444 N :
Additional assignments on connection of a temperature sensor cable
17-pin panel-mounting socket
with pin contacts
Core colour Pin Signal / function
2-core temperature sensor cable
GEL 2444
M M
GEL 2444
N M
brown 8 Temp +
blue 9 Temp –
4-core temperature sensor cable
GEL 2444
M N
GEL 2444
N N
brown 8 Temp1 +
white 9 Temp1 –
green 4 Temp2 +
pink 14 Temp2 –
6-core temperature sensor cable
GEL 2444
M P
GEL 2444
N P
brown 8 Temp1 +
white 9 Temp1 –
grey 6 Temp2 +
yellow 5 Temp2 –
green 4 Temp3 +
pink 14 Temp3 –
GEL 2444 P -
10-pin
female connector
(Mating view)
Pin Signal / function
1
1U
B
+ 5 V supply voltage
2U
1+
Signal track 1
3U
1–
Inverse signal track 1
4U
2+
Signal track 2
5U
2–
Inverse signal track 2
6U
Sense
5 V Sense
7U
N+
Signal reference track N
8U
N–
Inverse signal reference track N
90 V GND
10 Not used
