LookingupFRUinformation
FordetailedFRUinformation,suchastheFRUpartnumbersandsupportedcomputermodels,goto:
http:/www.lenovo.com/serviceparts-lookup
Locatingpartsonthesystemboard
Figure4“Locationsofthepartsandconnectorsonthesystemboard”onpage69showsthelocations
ofthepartsandconnectorsonthesystemboard.
Figure4.Locationsofthepartsandconnectorsonthesystemboard
1LCDpanelconnector12RearI/Oconnector
2Memoryslots(2)13Serialconnector
3Integratedcameracableconnector
14SATA3.0connector(Harddiskdrivesignalconnector)
4Coverpresenceswitchconnector(Intrusionswitch
connector)
15SATApowerconnector(Harddiskdriveandopticaldrive
powerconnector)
5Touchcontrolconnector(notenabled)16PS/2keyboardandPS/2mouseconnector
6Battery
17SATA3.0connector(Opticaldrivesignalconnector)
7ClearComplementaryMetalOxideSemiconductor
(CMOS)/Recoveryjumper
18Converterboardconnector
8ClearCMOS219Controlbuttonboardconnector
Chapter8.Locations69
