3.Liftthereleasepin1ontheslim-optical-drivebracket.Meanwhile,slidethebrackettotherearof
theserverasshowntoreleasethebracketfromthechassis.Then,lifttheslim-optical-drivebracket
outofthechassis.
Figure47.Removingtheslim-optical-drivebracket
Installingtheslim-optical-drivebracket
Toinstalltheslim-optical-drivebracket,dothefollowing:
1.Positionthebracketinthechassis,alignthefourslotsinthebracketwiththemountingstudsonthe
chassis,andthenslidethebrackettothefrontoftheserveruntilthepin1issnappedintoposition.
Figure48.Installingtheslim-optical-drivebracket
2.Reinstalltheslimopticaldriveifyouhaveremovedit.See“Installingtheslimopticaldrive”onpage62.
Chapter5.Replacinghardware71
