Systemboardcomponents

Thefollowingillustrationshowsthecomponentlocationsonthesystemboard.

Figure30.Systemboardcomponents

1M.2storage-modulepowerconnector

2Coin-cellbattery

3System-boardsignalconnector4Optical-drivepowerconnector

5System-boardpowerconnector1

6Backplanepowerconnector2

7Backplanepowerconnector1

8Systemfanconnector

9Memoryslotsformicroprocessor1(4)

10Microprocessorsocket1

11Memoryslotsformicroprocessor1(4)12System-boardpowerconnector2

13SD-moduleconnector14SATAconnector0(ports0–3)

15SATAconnector1(ports4–7)

16Frontpanelconnector

17Optical-drive2signalconnector

18RAIDupgradekeyconnector

19Optical-drive1signalconnector

20TPMconnector

21TSMPremiumconnector22I2CtoI2Cconnector

23PCIecardslot1formicroprocessor124PCIecardslot2formicroprocessor1

25PCIecardslot3formicroprocessor1

26AnyRAIDconnector1–2

27Intrusionswitchconnector

28Memoryslotsformicroprocessor2(4)

29Microprocessorsocket2

30Memoryslotsformicroprocessor2(4)

31PCIecardslot4formicroprocessor232PCIecardslot5formicroprocessor2

33PCIecardslot6formicroprocessor234PCIecardslot7formicroprocessor2

Chapter3.Productoverview47
