1.ConnectoneendoftheYcabletotheUSB3.0connectorontherearoftheexternaltapedrive.Then,
connecttheotherendoftheYcabletotwoavailableUSBconnectorsontheserver.
Figure142.Connectingtheexternaltapedrive
2.Verifyifthetapedriveworkscorrectly.
Forservicetechnicianonly:replacingthesystemboard
Attention:ThisproceduremustbeperformedbytrainedservicepersonnelofLenovo.Donotopenyourserveror
attemptanyrepairbeforereadingandunderstanding“Readthisfirst:safetyinformation”onpageiiiand“Guidelines”
onpage69.
CAUTION:
Hazardousmovingparts.Keepfingersandotherbodypartsaway.
CAUTION:
Theheatsinksandmicroprocessorsmightbeveryhot.Turnofftheserverandwaitseveralminutes
tolettheservercoolbeforeremovingtheservercover.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Note:Dependingonthemodel,yourservermightlookslightlydifferentfromtheillustrationsinthistopic.
Toreplacethesystemboard,dothefollowing:
1.Removeallexternalmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,
disconnectallpowercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedto
theserver.
174ThinkServerTD350UserGuideandHardwareMaintenanceManual
