7.Connectthepowerandsignalcable1totherearofthetapedrive.
Figure98.Connectingthepowerandsignalcabletotherearofthetapedrive
8.Dooneofthefollowing:
•Ifyouareinstallingatapedrive,savetheremovedprotectiveshieldincasethatyoulaterremove
thedriveandneedtheprotectiveshieldtocoverthedrivebay.
•Ifyouarereplacingatapedriveandareinstructedtoreturntheoldtapedrive,followallpackaging
instructions.Then,useanypackagingmaterialsthataresuppliedtoyouforshipping.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage180.
Installingorreplacingthemicroprocessor
Thistopiccontainsthefollowingitems:
•“Installingthesecondmicroprocessor”onpage138
•“Replacingthemicroprocessor”onpage142
Installingthesecondmicroprocessor
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Readthisfirst:safety
information”onpageiii
and“Guidelines”onpage69.
Dependingonthemodel,yourservermightcomewithoneortwomicroprocessors.Forservermodelswith
onemicroprocessor,themicroprocessorisinstalledinthemicroprocessorsocket1andthemicroprocessor
socket2isprotectedbyaplasticsocketcover.YoucanpurchaseamicroprocessoroptionkitfromLenovo
andinstallthesecondmicroprocessortoexpandsystemcapabilities.
CAUTION:
Turnofftheserverandwaitseveralminutestolettheservercoolbeforeremovingtheservercover.
138ThinkServerTD350UserGuideandHardwareMaintenanceManual
