1 12
2
0
MGMT
3 4
ID
1
3
4
9
5
6
8
7
2
Figure4.Rearviewoftheserver
1Powercordconnector2PowersupplystatusLED
3VGAconnector(DB-15)4Serialconnector
5Ethernetconnectorforsystemmanagement
6USB3.0connectors(4)
7Ethernetconnectors(RJ-45)(2)8Systemidentificationbutton/LED
9Expansioncardarea
Yourservermodelmighthaveoneortwohot-swapredundantpowersupplies.Eachhot-swapredundant
powersupplyhasonepowercordconnectorontherearoftheserver.Foreachhot-swapredundantpower
supply,theremightbeoneortwostatusLEDsonthepowersupplynearthepowercordconnector.For
informationaboutthestatusLEDs,see“Hot-swappowersupplystatusLEDs”onpage26
.
1Powercordconnector
Usedtoconnectthepowercord.
2PowersupplystatusLED
TheLEDindicatesthestatusofthepowersupply.
PowersupplystatusLEDDescription
Green
Thepowersupplyisconnectedtotheacpowersourceandis
workingnormally.
Off
Thepowersupplyisdisconnectedfromtheacpowersourceor
hasfailed.
Chapter3.Productoverview17
