48 NE1032T Installation Guide
ToinstalltheNE1032TinaniDataPlexrack,completethefollowingsteps:
1. Locate,record,andretaintheproductswitchinformationinordertoconfigureand
registeryourproduct.See“BeforeInstallingtheNE1032T”onpage 34.
Note: Ifthisswitchisareplacementswitch,copytheproductinformationfromthe
originalswitch
ontotheRIDlabelthatisshippedwithreplacementswitchand
affixthenewlabeltothebottomofthenewswitch.
2. Attachfrontmountingbrackets(Item1)andrearmountingbrackets(Item6)to
eachsideoftheswitchwithM4screws(Item2).Torquethescrewsto
approximately2
newton‐meters(Nm)+/‐0.1Nm(17.7inch‐pounds).
3. Fromthefront,slidetheswitchintotherackatthedesiredheight.
4. SecuretheswitchtothefrontrackpostswithM6screws(Item3),andclipnuts
(Item4).Torquethescrewstoapproximately5.7Nm+/‐0.1Nm
(50inch‐pounds).
1
2
6
3
4
