Lenovo ThinkSystem NE1032T User Manual

66 NE1032T Installation Guide
Replacing the Fan Module
Toreplaceahot‐swapfanmodule,completethefollowingsteps:
1. Selectanemptyfanmodulebayontherearoftheswitch.Ifthetargetbayis
coveredbyablankfanfillerplate,loosentheretainerscrewandslidethefillerplate
outoftheslot.
2. Removethenew
fanmodulefromtheantistaticshieldedbag.
3. Slidethefanmoduleintothecardguidesintheopenslotandgentlypushitallthe
wayintotheslot,sothatitfirmlyengageswiththeconnector(seetheillustration).
Eachfanmodulehasamechanicalguidekeytoprevent
youfrominsertingthe
moduleincorrectly.
4. Tightentheretainingscrewonthefanmodule.Torquethescrewtoapproximately
0.25Nm+/‐0.1Nm(2inch‐pounds).
5. Makesurethatthefanmodule’sLEDislit.
Retainer Screw
