CAUTION:
The battery is a lithium ion battery. To avoid possible explosion, do not burn the battery. Exchange it
only with the approved part. Recycle or discard the battery as instructed by local regulations.
Attention:
• Go over
“Installation Guidelines” on page 137 to ensure that you work safely.
• Touch the static-protective package that contains the component to any unpainted metal surface on the
server; then, remove it from the package and place it on a static-protective surface.
Note: Follow any special handling and installation instructions that come with the replacement battery.
Procedure
Step 1. Place the CMOS battery on top of the socket with the positive (+) symbol facing up, and press the
battery into the seat until it clicks in place.
Figure 44. Installing the CMOS battery
After this task is completed
1. Proceed to complete the parts replacement (see
“Complete the parts replacement” on page 282).
2. Reset date, time, and all the passwords.
Demo video
Watch the procedure on YouTube
Fan and fan cage replacement
Follow instructions in this section to remove or install the fans and the fan cage assembly.
Remove the fan cage assembly
Follow instructions in this section to remove the fan cage assembly.
About this task
S002
Chapter 4. Hardware replacement procedures 153
