x16/x16 (x8 lanes) PCIe riser card
See this section to locate the connectors on the x16/x16 (x8 lanes) PCIe riser card.
Figure 15. x16/x16 (x8 lanes) PCIe riser card connectors
Table 11. x16/x16 (x8 lanes) PCIe riser card connectors
1 PCIe full-height riser 3 PCI Express 3.0 x16 (x8 lane) (Slot 2)
2 PCI Express 3.0 x16 (x8 lane) (Slot 1)
Chapter 2. Server components 35
