x16/x16 PCIe FH riser cage
See this section to locate the connectors in the x16/x16 4U PCIe riser cage.
Figure 17. x16/x16 PCIe FH Riser Cage
Table 12. Connectors on x16/x16 PCIe FH Riser Cage
1 Auxiliary power connector
3 PCI Express 3.0 x16 (slot 2/10)
2 Auxiliary power connector
4 PCI Express 3.0 x16 (slot 4/12)
Chapter 2. Server components 37
