Lenze 8400 BaseLine C - Parameters with Bit-Coded Setting

10 Parameter reference
10.1 Structure of the parameter descriptions
232
Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Parameter setting in the »Engineer«
In the »Engineer«, a list field is used for parameter setting:
10.1.3.3 Parameters with bit-coded setting
Description structure
Parameter setting in the »Engineer«
The »Engineer« uses a dialog box for parameter setting in which the individual bits can be set or re-
set. Alternatively, the value can be entered as a decimal or hexadecimal value:
Parameter | Name:
Cxxxxx | _____________
Data type: _______
Index: _______
Description
Value is bit-coded:
Bit 0
...
Bit 31
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
