Lenze 8400 BaseLine C - Operationenabled

Lenze · 8400 BaseLine C · Reference manual · DMS 1.6 EN · 01/2014 · TD05 59
4 Device control (DCTRL)
4.2 Device states
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.2.6 OperationEnabled
In the "OperationEnabled" state
• is the controller if the controller inhibit is deactivated and no trouble ("Trouble") and fault
("Fault") are existent.
• the operation is enabled and the motor follows the setpoint defined by the active application
(in case of sensorless vector control only after the magnetisation process is completed).
Depending on certain conditions, a state change takes place based on the "OperationEnabled" de-
vice state.
Related topics:
Process data assignment for control via CAN
( 137)
LED DRIVE READY LED DRIVE ERROR Display in C137 Display in status word 1 (C150)
Bit 11 Bit 10 Bit 9 Bit 8
OFFOperationEnabled0101
Change condition Changeover to the device state
Control bit "EnableOperation" in control word wCANControl = "0"
OR terminal RFR = LOW level (controller inhibit).
SwitchedON
Control bit "SwitchOn" = "0". ReadyToSwitchON
Undervoltage in the DC bus. Trouble/Fault (dependent on C600/1)
Error with error response "Trouble" occurs. Trouble
