4 Device control (DCTRL)
4.1 Device commands
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Device commands - short overview
Activate device command
When an online connection has been established, you can simply use the »Engineer« to activate a
device command by selecting the corresponding option from the Parameter tab in C002/x
("0: Off"
or "1: On / start").
• Alternatively, the device command can also be activated via e.g. keypad or through a master
control by writing to C002/x
.
• Some of the frequently used device commands (such as "Save parameter settings") can also be
executed via toolbar icons of the »Engineer« when an online connection has been established:
C00002
Subcode:
Device command Controller inhibit re-
quired
Status information
1 Load Lenze setting
 dynamic
2 Loading parameter settings
 dynamic
7 Save parameter settings
dynamic
12 Import EPM data
static
16 Enable/Inhibit controller
static
17 Activate/Deactivate quick stop
static
19 Reset error
static
21 Delete logbook
static
23 Identify motor parameters
 dynamic
26 CAN reset node
static
* Subcodes which are not listed are reserved for future extensions.
Symbol Function
Enable controller
Inhibit controller
Save parameter settings
 Note!
Device commands that can be executed via the toolbar of the »Engineers« always affect
the element currently selected in the Project view including all subelements!
• If no controller, but e.g. a system module is selected in the Project view, the correspon-
ding device command will be activated in all lower-level controllers having an online
connection with the »Engineer«.
Before the desired action is carried out, a confirmation prompt appears first, asking whe-
ther the action is really to be carried out.
