Commissioning
Parameter setting with the XT EMZ9371BC keypad
Vector control
7
143
EDK82EV222 DE/EN/FR 13.0
CommentSwitch−on sequence
14. Start the motor parameter identification (C0148) Only when the motor is cold!
A Ensure that the controller is inhibited Terminal X3/28 = LOW
B Set C0148 = 1 Press
C Enable the controller l Terminal X3/28 = HIGH
l The identification starts:
– Segment is off
– The motor consumes current and makes a
high−pitched" tone.
– The motor does not rotate!
D If segment becomes active again after approx. 30 s,
inhibit controller again.
l Terminal X3/28 = LOW
l Identification is completed.
l Calculated and stored:
– V/f rated frequency (C0015)
– Slip compensation (C0021)
– Motor stator inductance (C0092)
l Measured and stored:
– Motor stator resistance (C0084) = Total
resistance of motor cable and motor
15. Activate the motor temperature monitoring (C0119) if you
have connected a PTC or thermal contact to terminal X2.2
Lenze setting: switched off
Possible settings( 152)
When all settings are complete:
16. Select setpoint E.g. via potentiometer at terminals 7, 8, 9
17. Enable the controller Terminal X3/28 = HIGH
18. The drive is now running. If the drive does not start, additionally press
