Lenze Global Drive 9300 Servo PLC Series User Manual

9300 Servo PLC
Appendix
3-19
L
ServoPLC EN 2.0
Code InfoPossible settingsLCDCode Info
SelectionLenze
LCD
C0094 Password 0 Keypad password protection
• Parameter password protection for the keypad
• When the password is activated, only user-menu codes
can be accessed.
• For extended password protection please see C0096.
0 {1} 9999
0 = No password protection
[C0095] Rotor pos adj 0 Rotor position adjustment of a synchronous motor
• C0058 displays the zero angle of the rotor
• C0095 = 1 starts position adjustment
0 Not active
1Active
C0096 AIF/CAN prot. AIF-/CAN password protection
• Extended password protection for bus systems when
password is activated (C0094).
• All codes in the user menu can be accessed.
0 No password protection
1 Read protection
2 Write protection
3 Read/write protection
1 0 AIF password protection
2 0 CAN password protection
C0099 S/W version
g
Software version of operating system
C0105 QSP Tif 0.000 Deceleration time for quick stop (QSP)
• Related to speed change 0 ... n
max.
0.000 {0.001 sec} 999.900
C0108 FCODE (gain) Freely configurable codes (relative analog signals)
-199.99 {0.01 %} 199.99
1 100.00 FCODE_nC108_1_a
2 100.00 FCODE_nC108_2_a
C0109 FCODE (offset) Freely configurable codes (relative analog signals)
-199.99 {0.01 %} 199.99
1 0.00 FCODE_nC109_1_a
2 0.00 FCODE_nC109_2_a
C0114 DIGIN pol Terminal polarity
0 HIGH active
1LOWactive
1 1 X5/E1
2 1 X5/E2
3 0 X5/E3
4 0 X5/E4
5 0 X5/E5
C0118 DIGOUT pol Terminal polarity
0 HIGH active
1LOWactive
1 0 X5/A1
2 0 X5/A2
3 0 X5/A3
4 0 X5/A4
C0121 OH7 limit 150 Temperature threshold prewarning motor temperature
“TMot > C0121” (error OH7)
45 {1 °C} 150
C0122 OH4 limit 85 Temperature threshold prewarning heatsink temperature
“Tht > C0122” (error OH4)
45 {1 °C} 85
