9300 Servo PLC
Appendix
3-18
L
ServoPLC EN 2.0
Code InfoPossible settingsLCDCode Info
SelectionLenze
LCD
[C0086] Mot type Lenze inverter motor in delta connection • The temperature monitoring via resolver or encoder
cable is deactivated automatically, i.e.:
C0583 = 3
C0584 = 3
C0594 = 3
250 DXRA071-12-87
251 DXRA071-22-87
252 DXRA080-12-87
254 DXRA090-12-87
255 DXRA090-32-87
256 DXRA100-22-87
257 DXRA100-32-87
258 DXRA112-12-87
259 DXRA132-12-87
260 DXRA132-22-87
261 DXRA160-12-87
262 DXRA160-22-87
263 DXRA180-12-87
264 DXRA180-22-87
DXRAXX071-12, f
d
: 87Hz
DXRAXX071-22, f
d
: 87Hz
DXRAXX080-12, f
d
: 87Hz
DXRAXX090-12, f
d
: 87Hz
DXRAXX090-32, f
d
: 87Hz
DXRAXX100-22, f
d
: 87Hz
DXRAXX100-32, f
d
: 87Hz
DXRAXX112-12, f
d
: 87Hz
DXRAXX132-12, f
d
: 87Hz
DXRAXX132-22, f
d
: 87Hz
DXRAXX160-12, f
d
: 87Hz
DXRAXX160-22, f
d
: 87Hz
DXRAXX180-12, f
d
: 87Hz
DXRAXX180-22, f
d
: 87Hz
265 30kW-ASM-87
266 37kW-ASM-87
267 45kW-ASM-87
268 55kW-ASM-87
269 75kW-ASM-87
[C0087] Mot speed à Rated motor speed
à depending on C0086
• Change of C0086 resets value to the assigned default
setting
• Alteration sets C0086 = 0
300 {1 rpm} 16000
[C0088] Mot current à Rated motor current
à depending on C0086
• Change of C0086 resets value to the assigned default
setting
• Alteration sets C0086 = 0
0.5 {0.1 A} 500.0
[C0089] Mot frequency à Rated motor frequency
à depending on C0086
• Change of C0086 resets value to the assigned default
setting
• Alteration sets C0086 = 0
10 {1 Hz} 1000
[C0090] Mot voltage à Rated motor voltage
à depending on C0086
• Change of C0086 resets value to the assigned default
setting
• Alteration sets C0086 = 0
50 {1 V} 500
[C0091] Mot cos-phi (p.f.) à Motor cos ϕ
à depending on C0086
• Change of C0086 resets value to the assigned default
setting
• Alteration sets C0086 = 0
0.50 {0.01} 1.00
C0093 DRIVE ident
g
Controller identification
0 Def. power stage
1 No power stage
93xx 93xx
