Lenze Global Drive 9300 Servo PLC Series User Manual

9300 Servo PLC
Appendix
3-17
L
ServoPLC EN 2.0
Code InfoPossible settingsLCDCode Info
SelectionLenze
LCD
[C0086] Mot type New generation Lenze synchronous servo motors • Integrated temperature monitoring via resolver or
encoder cable
• The temperature monitoring via resolver or encoder
cable is activated automatically, i.e.:
C0583 = 0
C0584 = 2
C0594 = 0
108 DSKS36-13-200
109 DSKS36-23-200
110 DSKS56-23-150
111 DSKS56-33-150
112 DSKS71-13-150
113 DFKS71-13-150
114 DSKS71-23-150
115 DFKS71-23-150
116 DSKS71-33-150
117 DFKS71-33-150
160 DSKS56-23-190
161 DSKS56-33-200
162 DFKS71-03-170
163 DSKS71-03-165
164 DSKS71-13-185
165 DFKS71-13-180
166 DSKS71-33-180
167 DFKS71-33-175
MDSKSXX036-13, f
r
:200Hz
MDSKSXX036-23, f
r
:200Hz
MDSKSXX056-23, f
r
: 150Hz
MDSKSXX056-33, f
r
: 150Hz
MDSKSXX071-13, f
r
: 150Hz
MDFKSXX071-13, f
r
: 150Hz
MDSKSXX071-23, f
r
: 150Hz
MDFKSXX071-23, f
r
: 150Hz
MDSKSXX071-33, f
r
: 150Hz
MDFKSXX071-33, f
r
: 150Hz
MDSKSXX56-23-190,f
r
:190Hz
MDSKSXX56-33-200,f
r
:200Hz
MDFKSXX71-03-170,f
r
:170Hz
MDSKSXX71-03-165,f
r
:165Hz
MDSKSXX71-13-185,f
r
:185Hz
MDFKSXX71-13-180,f
r
:180Hz
MDSKSXX71-33-180,f
r
:180Hz
MDFKSXX71-33-175,f
r
:175Hz
Lenze inverter motor in star c onnection • The temperature monitoring via resolver or encoder
cable is deactivated automatically, i.e.:
C0583 = 3
C0584 = 3
C0594 = 3
210 DXRA071-12-50
211 DXRA071-22-50
212 DXRA080-12-50
214 DXRA090-12-50
215 DXRA090-32-50
216 DXRA100-22-50
217 DXRA100-32-50
218 DXRA112-12-50
219 DXRA132-12-50
220 DXRA132-22-50
221 DXRA160-12-50
222 DXRA160-22-50
223 DXRA180-12-50
224 DXRA180-22-50
DXRAXX071-12, f
d
: 50Hz
DXRAXX071-22, f
d
: 50Hz
DXRAXX080-12, f
d
: 50Hz
DXRAXX090-12, f
d
: 50Hz
DXRAXX090-32, f
d
: 50Hz
DXRAXX100-22, f
d
: 50Hz
DXRAXX100-32, f
d
: 50Hz
DXRAXX112-12, f
d
: 50Hz
DXRAXX132-12, f
d
: 50Hz
DXRAXX132-22, f
d
: 50Hz
DXRAXX160-12, f
d
: 50Hz
DXRAXX160-22, f
d
: 50Hz
DXRAXX180-12, f
d
: 50Hz
DXRAXX180-22, f
d
: 50Hz
225 30kW-ASM-50
226 37kW-ASM-50
227 45kW-ASM-50
228 55kW-ASM-50
229 75kW-ASM-50
