9300 Servo PLC
Appendix
3-23
L
ServoPLC EN 2.0
Code InfoPossible settingsLCDCode Info
SelectionLenze
LCD
[C0173] UG limit 1 Adaptation of DC-bus voltage thresholds
• Check during commissioning, and adapt i f necessary
• All drive components in DC-bus links must ha ve the
same thresholds
0 Mains < 400 V; with or without brake unit
1 Mains = 400 V; with or without brake unit
2 Mains = 460 V; with or without brake unit
3 Mains = 480 V; without brake unit
4 Mains = 480 V; with brake unit
C0178 Op timer
g
Elapsed operating time meter
• Time the controller was enabled
0 {1 sec} 4294967295
C0179 Mains timer
g
Elapsed time meter
• Power-up time
0 {1 sec} 4294967295
C0183 Diagnostics
g
Drive diagnostics
• Indicates error and status information.
• If several error or status information occur at the same
time, the information with the lowest number will be
displayed
0OK
101 Initialisation
102 TRIP/error
103 Emergency stop
104 IMP message
105 Power off
111 BSP C135
112 BSP AIF
113 BSP CAN
121 RSP terminal 28
122 RSP internal 1
123 RSP internal 2
124 RSP C135/STOP
125 RSP AIF
126 RSP CAN
141 Power-up inhibit
142 IMP inhibit
151 QSP external terminal
152 QSP C135/STOP
153 QSP AIF
154 QSP CAN
250 Warning
No fault
Initialization phase
TRIP active
Emergency stop was released
Message active
Operation inhibit C135
Operation inhibit AIF
Operation inhibit CAN
Controller inhibited via X5/28
DCTRL-CINH1
DCTRL-CINH2
STOP key of 9371BB
Controller inhibi ted via AIF
Controller inhibited via CAN
Restart protection active
Power outputs with high resistance
QSP via MCTRL-QSP
QSP via STOP key
QSP via AIF
QSP via CAN
Warning active (C0168)
C0199 BuildNumber
g
BS software creation number
C0200 S/W Id
g
BS software product c ode
C0201 S/W date
g
BS software creation date
C0202 Internal ID
g
Internal designation
1 EKZ1
2 EKZ2
3 EKZ3
4 EKZ4
C0203 Comm.-No.
g
Commission number
C0204 Serial-No.
g
Serial number
C0206 Product date
g
Production date
C0207 DL info 1
g
Download info 1
C0208 DL info 2
g
Download info 2
C0209 DL info 3
g
Download info 3
