9300 Servo PLC
Appendix
3-29
L
ServoPLC EN 2.0
Code InfoPossible settingsLCDCode Info
SelectionLenze
LCD
C0517 User menu User menu with up to 32 entries
The numbers of desired codes are entered under the
subcodes.
The data is input in xxx.yy format
xxx: Code number
yy: Subcode for code
There is no check whether the entered code exists.
0.00 {0.01} 7999.00
1 51.00 C0051/0 MCTRL-NACT
2 54.00 C0054/0 Imot
3 56.00 C0056/0 MCTRL-MSET2
4 0.00 Not assigned
5 0.00 Not assigned
6 183.00 C0183/0 Diagnostics
7 168.01 C0168/1 Fail number
8 86.00 C0086/0 Mot type
9 22.00 C0022/0 Imax current
10 0.00 Not assigned
11 11.00 C0011/0 Nmax
12 0.00 Not assigned
13 0.00 Not assigned
14 105.00 C0105/0 QSP Tif
15 0.00 Not assigned
16 70.00 C0070/0 Vp speed CTRL
17 71.00 C0071/0 Tn speed CTRL
18 1500.00 C1500/0
19 2100.00 C2100/0 Time slice
20 2102.00 C2102/0 Task switch
21 2104.00 C2104/0 PLC Autorun
22 0.00
23 2108.00 C2108/0 PLC run/stop
24 0.00 Not assigned
... ... ...
30 0.00 Not assigned
31 94.00 C0094/0 Password
32 3.00 C0003/0 Par save
[C0540] Function 2 Digital frequency output DFOUT_IO_DigitalFrequency:
Function
X9 is inhibited, if 0, 1, or 2 had been selected.
DFOUT_nIn_v = 0, if 4 or 5 had been selected.
The input signals are elctrically buffered.
0DFOUT_nOut_vas%
1DFOUT_nOut_vasrpm
2 Incremental encoder emulation + zero pulse
4 X9 is output on X10
5 X8 is output on X10
C0545 PH offset 0 Digital frequency output DFOUT_IO_DigitalFrequency:
Angle offset of the zero pulse with incremental encoder
simulation (1 rev. = 65535 inc)
0 {1 inc} 65535
C0547 DFOUT_nOut_v
g
Digital frequency output DFOUT_IO_DigitalFrequency:
DFOUT_nOut_v as analog value (if C0540 = 0)
-199.99 {0.01 %} 199.99
