9300 Servo PLC
Appendix
3-28
L
ServoPLC EN 2.0
Code InfoPossible settingsLCDCode Info
SelectionLenze
LCD
C0473 FCODE abs Freely configurable codes (absolute analog signals)
-32767 {1} 32767
1 1 FCODE_bC473_1_a
2 1 FCODE_bC473_2_a
3 0 FCODE_bC473_3_a
... ... ...
10 0 FCODE_bC473_10_a
C0474 FCODE PH Freely configurable code (angle/signals)
-2147483648 {1} 2147483647
1 0 FCODE_dnC474_1_p
... ... ...
5 0 FCODE_dnC474_5_p
C0475 FCODE DF Freely configurable code (angle difference signal)
-16000 {1 rpm} 16000
1 0 FCODE_nC475_1_v
2 0 FCODE_nC475_2_v
[C0490] Feedback pos 0 Feedback system for the speed controller
• C0490 = 0, 1, 2 can be mixed with
C0495 = 0, 1, 2.
• C0490 = 3, 4 sets C0495 to the same value.
0 Resolver at X7
1 Encoder TTL at X8
2 sin/cos encoder at X8
3 Absolute value encoder ST a t X8
4 Absolute value encoder MT at X8
[C0495] Feedback n Feedback system for the speed controller
• C0495 = 0, 1, 2 can be mixed with
C0490 = 0, 1, 2.
• C0495 = 3, 4 sets C0490 to the same value.
0 Resolver at X7
1 Encoder TTL at X8
2 sin/cos encoder at X8
3 Absol ute value encoder ST (singl e turn) at X8
4 Absolute value encoder MT (multi turn) at X8
C0497 Nact filter 2.0 Actual speed value filter time constant PT1
0.0 {0.1 ms} 50.0
0 ms = switched off
