9300 Servo PLC
Appendix
3-27
L
ServoPLC EN 2.0
Code InfoPossible settingsLCDCode Info
SelectionLenze
LCD
C0431 DFIN TP EDGE 0 Digital frequency input DFIN_IO_DigitalFrequency:
Touch probe activation
• For touch probe via digital input X5/E5
(C0428 = 1)
0 Activation with positive signal
1 Activation with negative signal
C0434 DIS: IN
g
Analog output terminal 62 (AOUT1_nOut_a)
-199.99 {0.01 %} 199.99
C0439 DIS: AOUT2
g
Analog output terminal 63 (AOUT2_nOut_a)
-199.99 {0.01 %} 199.99
C0441 DIS: IN
g
Monitoring signal state bus (STATE_BUS_bOut_b)
01
C0443 DIS: DIGIT-OUT
g
Digital inputs
0 {dec} 255
Decimal value is bit-coded:
Bit 0 DIGIN_bIn1_b
Bit 1 DIGIN_bIn2_b
Bit 2 DIGIN_bIn3_b
Bit 3 DIGIN_bIn4_b
Bit 4 DIGIN_bIn5_b
Bit 5 STATE-BUS_bIn_b
Bit 6 DIGIN_bCInh_b
Bit7 Notassigned
X5/E1
X5/E2
X5/E3
X5/E4
X5/E5
C0444 DIS: DIGOUT g Digital outputs
01
1 DIGOUT_bOut1_b X5/A1
2 DIGOUT_bOut2_b X5/A2
3 DIGOUT_bOut3_b X5/A3
4 DIGOUT_bOut4_b X5/A4
[C0469] Fct STP key 2 Function of the S TOP key of the operating module
• Function will be activated when pressing the STOP key.
0 Deactivated
1 Controller inhibit
2QSP
C0470 FCODE 8bit Freely configurable c odes (digital signals)
• C0470 has the same memory address as code C0471.
0 {1} 255
1 0 C0470/1 = C0471, bit 0 ... 7
2 0 C0470/2 = C0471, bit 8 ... 15
3 0 C0470/3 = C0471, bit 16 ... 23
4 0 C0470/4 = C0471, bit 24 ... 31
C0471 FCODE 32bit 0 Freely configurable codes (digital signals)
• Variables assigned via FCODE_FreeCodes:
FCODE_bC471Bit0_b ... FCODE_bC471Bit31_b
• C0471 has the same memory address as code C0470.
0 {1} 4294967296
C0472 FCODE analog Freely configurable codes (relative analog signals)
-199.99 {0.01 %} 199.99
1 0 FCODE_bC472_1_a
2 0 FCODE_bC472_2_a
3 100 FCODE_bC472_3_a
4 0 FCODE_bC472_4_a
... ... ...
20 0 FCODE_bC472_20_a
