9300 Servo PLC
Appendix
3-26
L
ServoPLC EN 2.0
Code InfoPossible settingsLCDCode Info
SelectionLenze
LCD
C0365 DIS:CAN activ
g
Input signal CAN active
0CANnotactive
1CANactive
C0366 Sync response 1 System bus: Sync response
0 No response
1 Response to Sync
No response
PLC does not response to a sync telegram by sending a
CAN1_OUT object
C0367 Sync Rx Id 128 System bus: Sync Rx identifier
Receive identifier of the sync telegram.
1 {1} 256
C0368 Sync Tx Id 128 System bus: Sync Tx identifier
Transmit identifier of the sync telegram.
1 {1} 256
C0369 Sync Tx Time 0 System bus: CAN sync send telegram cycle
• A sync telegram with the identifier of C0368 is sent
with the set cycle time.
0 {1} 65000
0=off
C0400 DIS: OUT
g
Analog input terminal 1/2 (AI N1_nIn_a)
-199.99 {0.01 %} 199.99
C0405 DIS: OUT
g
Analog input terminal 3/4 (AI N2_nIn_a)
-199.99 {0.01 %} 199.99
[C0416] Resolver adj 0 Correction of the resolver error
• With Lenze motors:
Read resolver error from the nameplate
0 {1} 99999999
[C0420] Encoder const 512 Encoder: Constant for encoder input X8
1 {1 inc/rev} 8192
[C0421] Enc voltage 5.00 Encoder: Encoder voltage supply
• WARNING: incorrect input may destroy the encoder
5.00 {0.1 V} 8.00
C0425 DFIN const 3 Digital frequency input DFIN_IO_DigitalFrequency:
Increments of the encoder input
0 256 increments per revolution
1 512 increments per revolution
2 1024 increments per revolution
3 2048 increments per revolution
4 4096 increments per revolution
5 8192 increments per revolution
6 16384 increments per revolution
C0426 DIS: OUT
g
Digital frequency input DFIN_IO_DigitalFrequency:
DFIN_nIn_v
-32767 {1 rpm} 32767
C0427 DFIN function 0 Digital frequency input DFIN_IO_DigitalFrequency:
Type of the digital frequency signal
0 2 phases
1 A = Speed / B = Direction
2 A or B = Speed or direction
C0428 DFIN TP sel. 0 Digital frequency input DFIN_IO_DigitalFrequency:
Touch probe selection
0 Touch probe via zero pulse
1 Touc h-Probe through digital input X5/E5
C0429 TP delay 0 Digital frequency input DFIN_IO_DigitalFrequency:
Touch probe delay
• Compensation of delay times of TP signal source at
X5/E5
-32767 {1 inc} 32767
