9300 Servo PLC
Appendix
3-25
L
ServoPLC EN 2.0
Code InfoPossible settingsLCDCode Info
SelectionLenze
LCD
C0357 CE monit time System bus: Monitoring time for process data input objects
0 {1 msec} 65000
1 3000 CE1monit time
2 3000 CE2monit time
3 3000 CE3monit time
C0358 Reset node 0 System bus: Reset node
0 No function
1CANresetnode
C0359 CAN state
g
System bus: Status
0 Operational
1 Pre-Operational
2 Warning
3Busoff
C0360 CAN message
g
System bus: Telegram counter
(number of telegrams)
• For values > 65535 counting restarts with 0
0 {1 msec} 65535
1 All sent (without free CAN objects)
2 All received (without free CAN objects)
3 Sent to CAN1_OUT
4 Sent to CAN2_OUT
5 Sent to CAN3_OUT
6 Sent to parameter channel 1
7 Sent to parameter channel 2
8 Received by CAN1_IN
9 Received by CAN2_IN
10 Received by CAN3_IN
11 Received from parameter channel 1
12 Received from parameter channel 2
C0361 Load IN/OUT
g
System bus: Bus load
• Trouble-free operation demands that the total bus load
(all connected devices) does not e xceed 80 %.
0 {1 %} 100
1 All sent (without free CAN objects)
2 All received (without free CAN objects)
3 Sent to CAN1_OUT
4 Sent to CAN2_OUT
5 Sent to CAN3_OUT
6 Sent to parameter channel 1
7 Sent to parameter channel 2
8 Received by CAN1_IN
9 Received by CAN2_IN
10 Received by CAN3_IN
11 Received from parameter channel 1
12 Received from parameter channel 2
C0362 Sync cycle
g
System bus: Time between two sync telegrams
(in preparation)
1{1msec}30
C0363 Sync corr 1 System bus: Sync c orrection increments
10.2µs/ms
20.4µs/ms
30.6µs/ms
40.8µs/ms
51.0µs/ms
