9300 Servo PLC
Appendix
3-15
L
ServoPLC EN 2.0
Code InfoPossible settingsLCDCode Info
SelectionLenze
LCD
C0067 Act trip
g
Current error message
C0070 Vp speed CTRL à V
pn
Speed controller
à depending on C0086
• Change of C0086 resets value to the assigned default
setting
0.0 {0.5} 255.0
C0071 Tn speed CTRL à T
nn
Speed controller
à depending on C0086
• Change of C0086 resets value to the assigned default
setting
1.0 {0.5 ms} 600.0
>512 ms = switched off
C0072 Td speed CTRL 0.0 T
dn
Speed controller
0.0 {0.1 ms} 32.0
C0075 Vp curr CTRL à V
pi
Current controller
à depending on C0086
• Change of C0086 resets value to the assigned default
setting
0.00 {0.01} 15.99
C0076 Tn curr CTRL à T
ni
Current controller
à depending on C0086
• Change of C0086 resets value to the assigned default
setting
0.5 {0.1 ms} 2000.0
2000 ms = switched off
C0077 Vp field CTRL 0.25 V
pF
field controller
0.00 {0.01} 15.99
C0078 Tn field CTRL 15.0 T
nF
field controller
1.0 {0.5 ms} 8000.0
8000 ms = switched off
[C0081] Mot power à Rated motor power acc. to nameplate
à depending on C0086
• Change of C0086 resets value to the assigned default
setting
• alteration sets C0086 = 0
0.01 {0.01 kW} 500.00
[C0084] Mot Rs à Stator resistance of the motor
à depending on C0086
• Change of C0086 resets value to the assigned default
setting
• alteration sets C0086 = 0
0.00 {0.01 Ω} 100.00
[C0085] Mot Ls à Leakage inductance of the motor
à depending on C0086
• Change of C0086 resets value to the assigned default
setting
• Alteration sets C0086 = 0
0.00 {0.01 mH} 200.00
[C0086] Mot type
à Selection motor type
à depending on the controller
• Change of C0086 resets C0006, C0022, C0070,
C0071, C0081, C0084, C0085, C0087, C0088, C0089,
C0090, C0091 to the assigned default setting
0 COMMON No Lenze motor
