Electrical connection
Leuze electronic BPS 307i 48
Table 7.2: SSI (HOST / BUS IN) pin assignment
7.5.3 SSI connection cable KB 307
Table 7.3: SSI connection cable KB 307
Pin/terminal Designation Assignment
1 DATA+ + Data line SSI
(Output electrically isolated)
2 DATA- - Data line SSI
(Output electrically isolated)
3 CLK+ + Clock line SSI
(Input electrically isolated)
4 CLK- - Clock line SSI
(Input electrically isolated)
5 FE Functional earth
Thread (M12 plug)
Cable gland
Functional earth
(housing)
Connection cable shield.
The shield of the connection cable is on the
thread of the M12 plug or on the screw fitting of
the cable bushing.
The thread or the screw fitting is part of the
metallic housing. The housing is at the potential
of the functional earth via pin 5.
NOTICE
Use ready-made connection cables!
If possible, use the ready-made cables from Leuze electronic; see table 14.4.
NOTICE
Data cables for the SSI interface!
Use only shielded and twisted-pair cables as data line for the SSI interface.
Twisting: pin 1 with 2, pin 3 with 4
The shield must be connected at both ends.
KB 307-3000 KB 307-5000 FLEX
KB 307-10000 FLEX
Designation Assignment
WH GY FE Functional earth
WH-BK WH GNDIN Negative supply voltage (0 VDC)
BK BN VIN +18 … +30 VDC supply voltage
GY VT SWIO1 Sw. input/output 1 (configurable)
WH-GN BK SWIO2 Sw. input/output 2 (configurable)
WH-YE BU CLK- - Clock line SSI
(Input electrically isolated)
WH-RD GN DATA- - Data line SSI
(Output electrically isolated)
YE RD CLK+ + Clock line SSI
(Input electrically isolated)
