Technical data
Leuze electronic BPS 307i 77
13 Technical data
13.1 General specifications
Table 13.1: Optics
1 Reading field width [mm]
2 Reading distance [mm]
Figure 13.1: BPS reading field curve
Light source Laser diode
Wavelength 655 nm
Life expectancy laser diode 100,000 h (typ. at +25 °C)
Beam deflection Via rotating polygon wheel
Exit window Glass
Laser class 2 acc. to IEC 60825-1:2007 (EN 60825-1:2008-05);
II acc. to CDRH (U.S. 21 CFR 1040.10 with deviations cor-
responding to "Laser Notice No. 50" from June 24, 2007)
Working range 50 mm … 170 mm
At a reading distance of 50 mm, the reading field width is
120 mm.
At a reading distance beyond 100 mm, the reading field
width is 160 mm (see figure 13.1, BPS reading field
curve).
250 7550 100 150 200 250 30125 175 225 275
25
50
75
100
-25
-50
-75
-100
1
2
