Basic configuration
Leuze electronic BPS 307i 53
8.1.2 Setting the configuration of the SSI interface
 Set the parameters of the SSI interface via the webConfig tool or via connection hood MS 307 or
MK 307.
• Setting via the webConfig tool:
CONFIGURATION > OUTPUT; see chapter 9.3.2 "CONFIGURATION function"
• Setting via connection hood MS 307/MK 307:
see chapter 8.6 "Configuration via the switches of the connection hood"
8.2 Configuring the switching inputs/outputs
 Set the configuration of the switching inputs/outputs via the webConfig tool or via connection hood
MS 307 or MK 307.
• Setting via the webConfig tool:
CONFIGURATION > DEVICE; see chapter 9.3.2 "CONFIGURATION function"
• Setting via connection hood MS 307/MK 307:
see chapter 8.6 "Configuration via the switches of the connection hood"
8.3 Configuring the resolution for the position value
 Set the parameters for the resolution during position measurement via the webConfig tool or via con-
nection hood MS 307 or MK 307.
• Setting via the webConfig tool:
CONFIGURATION > OUTPUT; see chapter 9.3.2 "CONFIGURATION function"
• Setting via connection hood MS 307/MK 307:
see chapter 8.6 "Configuration via the switches of the connection hood"
8.4 Configuring speed monitoring with switching output
 Set the parameters for speed monitoring via the webConfig tool or via connection hood MS 307 or
MK 307.
• Setting via the webConfig tool:
•
Switching output function: CONFIGURATION > DEVICE > Switching inputs/outputs; see
chapter 9.3.2 "CONFIGURATION function"
• Speed limit values: CONFIGURATION > DATA PROCESSING > Speed > Monitoring; see
chapter 9.3.2 "CONFIGURATION function"
• Setting via connection hood MS 307/MK 307:
see chapter 8.6 "Configuration via the switches of the connection hood"
Devices with connection hood KB 307 can only be configured via the webConfig tool.
Devices with connection hood KB 307 can only be configured via the webConfig tool.
Devices with connection hood KB 307 can only be configured via the webConfig tool.
Devices with connection hood KB 307 can only be configured via the webConfig tool.
