Leuze electronic BPS 307i 61
• Firmware update
• User management
• Backup/Restore
9.3.2 CONFIGURATION function
Overview of the webConfig configuration functions
Figure 9.2:
CONFIGURATION webConfig function
Configuration of the SSI interface (
OUTPUT tab)
The SSI parameters and the formatting of the SSI host interface are configured via the
OUTPUT > HOST
formatting
function.
NOTICE
Rotary switch S2 of MS 307 or MK 307 to
0 if configuring with the webConfig tool!
 To configure with the webConfig tool, set rotary switch S2 on connection hood MS 307 or MK 307 to
switch position
0 ; see chapter 8.1.
NOTICE
Configuration changes only in the
Service operating mode!
 Changes made using the
CONFIGURATION function can only be performed in the Service operating
mode.
