Basic configuration
Leuze electronic BPS 307i 56
8.7 Setting configuration parameters to factory settings
Proceed as follows:
Set slide switch S1 to switch position Gray encoding.
Set rotary switch S2 to switch position
F
.
Restart the BPS.
The current parameter set of the BPS is overwritten with the parameter set containing the factory settings.
7 webConfig 0.7
•HIGH
Current speed
Below maxi-
mum speed
•LOW
Current speed
Above maxi-
mum speed
Activated
8 webConfig 2 Activated
9 webConfig 3 Activated
A webConfig 4 Activated
F Factory setting of the configuration parameters
Notice: Switch S1 must be set to switch position Gray encoding.
webConfig: The parameter value set via the webConfig tool is used.
Switch position Position resolution
[mm]
Maximum speed
[m/s]
Level of the switch-
ing output
Speed monitoring
All parameters that are not influenced by the position of the switch are configured via the web-
Config tool; see chapter 9.
In rotary switch positions
7
,
8
,
9
or
A
, the webConfig tool can be used, e.g., to change the reso-
lution of the position measurement or invert the mode of the switching inputs/outputs.
NOTICE
Rotary switch S2 on
0
if configuring with the webConfig tool!
To configure the BPS with the webConfig tool, rotary switch S2 on connection hood MK 307 or MS 307
must be set to switch position
0
.
