Care, maintenance and disposal
Leuze electronic BPS 307i 75
Affix the printed code over the defective section of bar code tape.
Figure 11.1: Checking the print results of the BCB repair kit (40 mm grid)
Figure 11.2: Checking the print results of the BCB8 repair kit (30 mm grid)
11.3 Disposing
For disposal observe the applicable national regulations regarding electronic components.
NOTICE
Printing coding
Select only those pages that are actually required.
Change the printer settings so that the bar code is not distorted.
Check the print results and measure the distance between two bar codes (see figure 11.1 and see
figure 11.2):
BCB: 40 mm
BCB8: 30 mm
Cut the code strips and arrange them next to one another. The code content must always increase or
decrease in increments of 30 mm or 40 mm.
Check that the printed values increase by 3 or 4.
000040 000044 000048 000052
40
BCB8
BCB8 BCB8
BCB8
BCB8
000018 000021 000024 000027 000030
30
