Technical data
Leuze electronic BPS 307i 78
Table 13.2: Measurement data
Table 13.3: Operating and display elements
Table 13.4: Mechanical data
Table 13.5: Environmental data
Reproducibility (3 sigma)
0.15 mm
Response time 8 ms
Output time 2 ms
Basis for contouring error calculation 4 ms
Measurement range 0 … 10,000,000 mm
Max. traverse rate 10 m/s
Display Monochromatic graphical display, 128 x 32 pixels,
With background lighting
Keyboard Two buttons
LEDs Two LEDs for power (PWR) and bus state (BUS),
two-colored (red/green)
Housing Diecast aluminum
Connection technology
• BPS with MS 307: M12 connectors
• BPS with MK 307: Terminal blocks with spring-cage
terminals (5-pin)
• BPS with KB 307: cable connection
Degree of protection IP 65
Weight Approx. 580 g (without connection hood)
Dimensions (without connection hood) (H x W x D) 108.7 mm x 100.0 mm x 48.3 mm
Dimensions (with MS 307 connection hood) (H x W x D) 108.7 mm x 100.0 mm x 48.3 mm
Dimensions (with MK 307 connection hood) (H x W x D) 147.4 mm x 100.0 mm x 48.3 mm
Dimensions (with KB 307 connection hood) (H x W x D) 108.7 mm x 100.0 mm x 48.3 mm
Dimensions of MS 307 connection hood (H x W x D) 64.0 mm x 43.5 mm x 33.5 mm
Dimensions of MK 307 connection hood (H x W x D) 64.0 mm x 43.5 mm x 83.5 mm
Dimensions of KB 307 connection hood (H x W x D) 64.0 mm x 43.5 mm x 18.1 mm
Air humidity Max. 90% rel. humidity, non-condensing
Vibration IEC 60068-2-6, test Fc
Shock
Continuous shock
IEC 60068-2-27, test Ea
Electromagnetic compatibility IEC 61000-6-3
IEC 61000-6-2 (contains IEC 61000-4-2, -3, -4, -5, -6)
