Levitronix BPS-2000 User Manual

User Manual for BPS-2000
www.levitronix.com
PL-4021-00, Rev06, DCO# 21-037
5
System Name
Article #
Pump Head
Controller
Standard Firmware
Motor
Note
BPS-2000.48 / 49
BPS-2000.4 / 5
BPS-2000.65 / 66
100-91461 / 62
100-90482 / 83
100-91496 / 97
LPP-2000.22 (High Flow)
LPP-2000.7 (High Pressure)
LPP-2000.21 (Sealless)
LPC-2000.1-01 / 2-01
LPC-2000.1-02 / 2-02
LPC-2000.1-14 / 2-14
E1.25 / E1.48
E2.25 / E2.48
E7.25 / E7.48
LPM-2000.2
LPM-2000.2
LPM-2000.2
Extension cables to be ordered according to Table 3 (pos. 4a and
4b).
Certifications: CE, IECEE CB scheme, ETL (NRTL).
BPS-2000.50 / 51
BPS-2000.10 / 11
BPS-2000.68 / 69
BPS-2000.30 / 31
BPS-2000.58 / 59
100-91463 / 64
100-90488 / 89
100-92499 / 500
100-91103 / 04
100-91471 / 72
LPP-2000.22 (High Flow)
LPP-2000.7 (High Pressure)
LPP-2000.21 (Sealless)
LPP-2000.14 (HF, Antistatic)
LPP-2000.20 (HP, Metallic)
LPC-2000.1-01 / 2-01
LPC-2000.1-02 / 2-02
LPC-2000.1-14 / 2-14
LPC-2000.1-01 / 2-01
LPC-2000.1-12 / 2-12
E1.25 / E1.48
E2.25 / E2.48
E7.25 / E7.48
E1.25 / E1.48
E5.25 / E5.48
LPM-2000.8
LPM-2000.8
LPM-2000.8
LPM-2000.8
LPM-2000.15
Extension cables to be ordered according to Table 3 (position 5a
and 5b). ATEX Cable Sealing System to be ordered according to
Table 4 (pos. 10).
Certifications: CE, IECEE CB scheme, ETL (NRTL), ATEX and
IECEx.
Note: LPM-2000.18 motor has integrated water cooling.
BPS-2000.78 / 79
BPS-2000.81 / 82
BPS-2000.77 / 75
100-91519 / 20
100-91522 / 23
100-91518 / 16
LPP-2000.22 (High Flow)
LPP-2000.7 (High Pressure)
LPP-2000.21 (Hybrid, Sealless)
LPC-2000.1-01 / 2-01
LPC-2000.1-02 / 2-02
LPC-2000.1-14 / 2-14
E1.25 / E1.48
E2.25 / E2.48
E7.25 / E7.48
LPM-2000.18
LPM-2000.18
LPM-2000.18
BPS-2000.53 / 54
BPS-2000.35 / 36
BPS-2000.71 / 72
BPS-2000.39 / 40
BPS-2000.56 / 47
100-91466 / 67
100-91152 / 53
100-91502 / 03
100-91173 / 74
100-91469 / 23
LPP-2000.22 (High Flow)
LPP-2000.7 (High Pressure)
LPP-2000.21 (Sealless)
LPP-2000.14 (HF, Antistatic)
LPP-2000.20 (HP, Metallic)
LPC-2000.1-01 / 2-01
LPC-2000.1-02 / 2-02
LPC-2000.1-14 / 2-14
LPC-2000.1-01 / 2-01
LPC-2000.1-12 / 2-12
E1.25 / E1.48
E2.25 / E2.48
E7.25 / E7.48
E1.25 / E1.48
E5.25 / E5.48
LPM-2000.9
LPM-2000.9
LPM-2000.9
LPM-2000.9
LPM-2000.17
Extension cable to be ordered according to Table 3.
Certifications: CE, IECEE CB scheme, ETL (NRTL), HazLoc Cl1
Div2
Table 1: Standard system configurations
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
1a
Pump Head
“High Flow Profile”
LPP-2000.22
100-91415
Impeller / Pump Housing
Sealing Ring / Fittings
Max. Flow / Max. Diff. Pressure
Max. Viscosity / Density / Liquid Temp.
PFA / PFA (wet parts) and PP+GF30 (reinforcing parts)
Kalrez

perfluoroelastomer
1

140 liters/min (37 gallons/min) / 4.2 bar (61 psi)
80 cP / 1.8 g/cm
3
/ 90°C (194°F)
1b
Pump Head
Antistatic
“High Flow Profile”
LPP-2000.14
100-90985
Impeller / Pump Housing
Sealing Ring / Fittings
PFA / PTFE+CFR (wet parts) Note: for solvent applications.
Kalrez

perfluoroelastomer
1

1c
Pump Head
“High Pressure Profile”
LPP-2000.7
100-90419
Impeller / Pump Housing
Sealing Ring / Fittings
Max. Flow / Max. Diff. Pressure
Max. Viscosity / Density / Liquid Temp.
PFA / PTFE (wet parts)
Kalrez

perfluoroelastomer
1

80 liters/min (21 gallons/min) / 6.9 bar (100 psi)
100 cP / 1.8 g/cm
3
/ 90°C (194°F)
1d
Pump Head
(Metallic)
“High Pressure Profile”
LPP-2000.20
100-91424
Impeller / Pump Housing
Sealing Ring / Fittings
Max. Flow / Max. Diff. Pressure
Max. Viscosity / Liquid Temp.
Stainless Steel / Stainless Steel
Unfilled FFPM (FFK) / VCR
®

2
80 liters/min (21 gallons/min) / 6.2 bar (90 psi)
20 cP / 90°C (194°F)
1e
Pump Head (Sealless)
“Hybrid Profile”
LPP-2000.21
100-91495
Impeller / Pump Housing
Sealing / Fittings
Max. Flow / Max. Diff. Pressure
Max. Viscosity / Liquid Temp.
PFA / PFA (wet parts) and PP+GF30 (reinforcing parts)
No sealing, welded PFA housing 
140 liters/min (37 gallons/min) / 5.7 bar (83 psi)
50 cP / 90°C (194°F)
2a
Motor
LPM-2000.2
100-10050
Housing
Cable / Connectors
ETFE (chemical resist.) coated Alu., waterproofed (IP67 without connectors)
2x 3m cables with FEP jacket / 2x circular (AMP types)
2b
2c
2d
Motor (ATEX, IECEx)
LPM-2000.8
LPM-2000.15
3
LPM-2000.18
100-10060
100-10164
100-10181
ATEX/IECEx Marking
Cable / Connectors
Water Cooling
II 3G Ex ec h IIC T5 Gc II 3D Ex h tc IIIC T100°C Dc
2x 3m cables with FEP jacket / 2x circular (M23, IP67)
LPM-2000.18 motor: integr. water cooling with Pillar S300 1/4" male fittings
2e
2f
Motor (HazLoc)
LPM-2000.9
LPM-2000.17
3
100-10112
100-10166
Hazardous Location Marking
Connectors
Class I, Div2, Groups A-D T5 Class II, Div2, Groups F-G T5

3a
Standalone
Controller
(User Panel)
LPC-2000.1-01 (HF)
LPC-2000.1-02 (HP)
LPC-2000.1-14 (HB)
LPC-2000.1-12 (HP)
3
100-30018
2
100-30019
2
100-30113
2
100-30098
2
Voltage / Power
1 x 200-240 V AC  10% / 2kW @ 50/60Hz
3 x 200-240 V AC  10% / 2kW @ 50/60Hz
Interfaces for
Standalone Controller
User panel to set speed (automatic storage on internal EEPROM)
PLC with
 4 - 20 mA
 0 - 24 V (optocoupler)
 0 - 24 V (relais)
3b
Extended
Controller
(PLC and USB)
LPC-2000.2-01 (HF
LPC-2000.2-02 (HP)
LPC-2000.1-14 (HB)
LPC-2000.2-12 (HP)
3
100-30021
2
100-30022
2
100-30114
2
100-30094
2
Interfaces for
Extended Controller
PLC with
up to 4 digital inputs 0 - 24V (optocoupler)
up to 4 digital outputs 0 - 24 V (relais)
up to 2 analog inputs 4 - 20mA
up to 2 analog inputs 0 - 10 V
up to 2 analog outputs 0 - 5 V
Table 2: Specification of standard components
Note 1: Kalrez

is a registered trademark of DuPont Dow Elastomers. Note 2: Supply and PLC connector included. Note 3: Pump head LPP-2000.20 operates with these motors and controllers only.
Note 4: Note 1: HF = High Flow, HP = High Pressure., HB = Hybrid, SL = Sealless
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
Sensor Cable
Power Cable
Sensor
Power
4a
4b
Extension Adaptor
Cable for Sensor (a)
and Power (b)
MCAS-600.1-05 (0.5 m)
MCAS-600.1-30 (3 m)
MCAS-600.1-50 (5 m)
MCAS-600.1-70 (7 m)
MCAS-600.1-100 (10 m)
MCAP-2000.1-05
MCAP-2000.1-30
MCAP-2000.1-50
MCAP-2000.1-70
MCAP-2000.1-100
190-10122
190-10123
190-10124
190-10101
190-10125
190-10208
190-10210
190-10211
190-10205
190-10212
Jacket Material
Connector Types
Connector Material
PVC
Circular AMP to D-SUB (a)/COMBICON (b)
Plastics (PA)
5a
5b
Extension Adaptor
Cable for Sensor (a)
and Power (b)
MCAS-600.3-05 (0.5 m)
MCAS-600.3-30 (3 m)
MCAS-600.3-50 (5 m)
MCAS-600.3-70 (7 m)
MCAS-600.3-100 (10 m)
MCAP-2000.3-05
MCAP-2000.3-30
MCAP-2000.3-50
MCAP-2000.3-70
MCAP-2000.3-100
190-10158
190-10159
190-10130
190-10160
190-10161
190-10219
190-10221
190-10222
190-10223
190-10224
Jacket Material
Connector Types
Connector Material
PVC
Circular M23 (IP67) to D-SUB (a)/COMBICON (b)
Metallic  Nickel coated
6a
6b
Interconnect
Cable for Sensor (a)
and Power (b)
MCIS-2000.1-05 (0.5 m)
MCIS-2000.1-30 (3 m)
MCIS-2000.1-50 (5 m)
MCIS-2000.1-70 (7 m)
MCIS-2000.1-100 (10 m)
MCIP-2000.1-05
MCIP-2000.1-30
MCIP-2000.1-50
MCIP-2000.1-70
MCIP-2000.1-100
190-10391
190-10392
190-10393
190-10394
190-10395
190-10396
190-10397
190-10398
190-10399
190-10400
Jacket Material
Connector Types
Connector Material
PVC
Circular M23 (IP67) to circular M23 (IP67)
Metallic  Nickel coated
Table 3: Specification of adaptor/extension cables
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
7a
Air Cooling Module
ACM-4.2
190-10139
Material / Connection Port
Air Pressure
PP (+ 40% Talc
~1 - 3 bar (14  43 psi)
7b
Air Cooling Module
ACM-4.3
190-10243
Material
PP-EL-S with conductive additive for operation with ATEX and HazLoc motors.
8a
Fan Cooling Module
FCM-2000.1
190-10390
Housing / Cable Spec.
Supply Spec. / IP Rating
PP (+ 20% Talcum) white / PP jacket, 3m, circular sealed M12 connector (PP).
24 VDC, 33.5 W / IP65 (fan is IP68 rated).
8b
Fan Cool. Module Cable
FCC-1.1-50 (5 m)
FCC-1.1-100 (10 m)
190-10407
190-10408
Specification
PP cable jacket with circular M12 connector (PP) to open wires
9a
Impeller Exchange Kit
(“High Pressure”)
IEK-2000.1
(for LPP-2000.7)
100-90529
Impeller (A) / O-Ring (B)
Pump /Motor Screws (C/D)
Imp. Exchange Tool IET-3.1 (E)
LPI-2000.1 in PFA / O-Ring, Kalrez

, 98.02 x 3.53
8pcs M8x40, Stainless Steel with PTFE coating / 4pcs M8x30, SS with PTFE coating
POM-C
9b
Impeller Exchange Kit“
(“High Flow”)
IEK-2000.2
(for LPP-2000.6/22)
100-90530
Impeller (A) / O-Ring (B)
Pump /Motor Screws (C/D)
Imp. Exchange Tool IET-3.1 (E)
LPI-2000.2 in PFA / O-Ring, Kalrez

, 98.02 x 3.53
8pcs M8x40, Stainless Steel with PTFE coating / 4pcs M8x30, SS with PTFE coating
POM-C
9c
Impeller Exchange Kit“
(“Antistatic”)
IEK-2000.8
(for LPP-2000.14)
100-90986
Impeller (A) / O-Ring (B)
Pump /Motor Screws (C/D)
Imp. Exchange Tool IET-3.1 (E)
LPI-2000.2 in PFA / O-Ring, Kalrez

, 98.02 x 3.53
8pcs M8x40, Stainless Steel with PTFE coating / 4pcs M8x30, SS
POM-C
10
ATEX Cable Sealing
ACS-A.1
(Roxtec)
100-90292
Sleeve (A) and Gasket (B)
Frame (C), 2x Cable Module (D)
Stainless Steel and EPDM
Roxylon (EPDM rubber)
Note: Lubricant (E) and measurement
plates (F) are included.
Table 4: Specification of accessories
