User Manual for BPS-2000
www.levitronix.com
PL-4021-00, Rev06, DCO# 21-037
4.2 Mechanical Installation of the Pump/Motor
4.2.1 Standard Installation Instructions and Information
Overheating of the Motor Power and Extension Power Cable
To prevent an overheating of the motor power and extension power
cables, do not roll-up or install several motor power cables in the same
cable channel. This is has especially to be considered when long motor
power cables are used.
▪ The motor can be fixed with four screws on the motor feet (see Figure 11).
▪ As an alternative the motor can be mounted with 12 screws on the back (see Figure 11).
▪ The motor can be mounted in either the horizontal or vertical position.
▪ Minimum cable bending radius according Table 6 to shall be followed for the installation of the
motor and extension/adaptor cables.
▪ Each motor is identified with a unique serial number. This serial number consists of a series of
6 digits were the 5th and the 6th digit representing the manufacturing year.
▪ To prevent an overheating of >90 °C of the motor power cable in extension power cable,
please don’t roll-up or install several motor power cables in the same cable channel.
4.2.2 Installation of Ex and Hazardous Location Certified Motors
Motors for ATEX / IECEx and Hazardous Location Cl1 Div2
applications. Only specific types of motors LPM-2000 are classified for
the use in Ex classified locations. Refer to the corresponding section in
the manual.
Motors for ATEX / IECEx and Hazardous Location Cl1 Div2
applications. Use only, if necessary, the cooling module ACM-4.3 for
motors installed in Ex classified locations. The use of other materials
for the air cooling module is not allowed.
Motors for ATEX / IECEx applications. Cable and cable glands of the
motor must be protected against impact energy.
For liquid temperatures above 75 °C in Ex applications active cooling
using the cooling module ACM-4.3 is needed.
