Repair information 4-17
2580+, 2581+, 2590+, 2591+
7. Disconnect the printhead cables (B) from the logic board, and move it back and out of the way.
8. Disconnect the carrier motor cable (J2) from the logic board.
9. Loosen the screw (D) holding the left side of the print unit.
To Next Page
