Lexmark S400 Series Service Manual

Diagnostic information 2-7
Lexmark S400 Series
1212 Watchdog Error Indicates printer system was
reset by Watchdog timer;
Subsystem stall failure.
Technical Support Center:
Unplug the All-In-One from the wall outlet;
wait a few seconds, then plug the All-In-
One back in and turn the power on. If the
problem remains, then replace the USB
cable.
Service:
Replace the system board. See “System
board removal” on page 4-28.
1213 Data Abort Error Firmware attempted to load or
store to an invalid address.
Technical Support Center:
Unplug the All-In-One from the wall outlet;
wait a few seconds, then plug the All-In-
One back in and turn the power on. If the
problem remains, then replace the USB
cable.
Service:
Replace the system board. See “System
board removal” on page 4-28.
1214 Invalid Processor Mode Error Indicates the ARM processor
was in an incorrect mode to
perform the requested
operation.
Technical Support Center:
Unplug the All-In-One from the wall outlet;
wait a few seconds, then plug the All-In-
One back in and turn the power on. If the
problem remains, then replace the USB
cable.
Service:
Replace the system board. See “System
board removal” on page 4-28.
1215 Math Error There is a problem doing math,
such as dividing by zero.
Technical Support Center:
Unplug the All-In-One from the wall outlet;
wait a few seconds, then plug the All-In-
One back in and turn the power on. If the
problem remains, then replace the USB
cable.
Service:
Replace the system board. See “System
board removal” on page 4-28.
1216 Mailbox Error Problem with the internal
mailbox messaging system.
Technical Support Center:
The printer will auto reset.
Service:
The printer will auto reset.
Error
Code
Name Description Action
